Ease-of-use

The plug-and-play functionality of the 3S allows you to start backing up your equipment the moment you take the unit out of the box. Gain automatic integration with Windows, Mac and Linux with a simple connection to a USB port.

Modern design

The sleek design of the 3S allows you to display it alongside your high-tech equipment for a sophisticated look. This unit can also be wall or desk-mounted for additional space savings.

Tech Specs

• Rating (VA/W) - 850VA/510W

Connection

• Output connection - 4 outlets with battery backup and surge protection + 4 outlets with surge protection

Electrical characteristics

• Nominal input voltage - 220 - 240 V
• Input voltage range - Up to 168-295 V (adjustable)
• Output voltage - 240V (adjustable to 220V/230V/240V)
• Input frequency range - 50 / 60 Hz (46 - 65 Hz working range)
• Input protection - 10A resettable circuit breaker

Battery

• Battery type - Compact, sealed lead acid battery (replaceable)
• Battery test - Yes
• Cold start (no mains power) - Yes
• Deep-discharge protection - Yes
• Battery replacement indicator - LED
• Desktop PC* - 20 minutes
• Gaming PC / Workstation* - 9 minutes

Features

• Communication - USB port (HID-compliant) for automatic integration with most common operating systems (Windows & Mac OS)
• USB charge - 2 USB ports (2A max)
• Phone/xDSL line protection - Yes

Operating conditions, Standards and Approvals

• Operating temperature - 0 to 40°C
• Operationg elevation - 0 to 3000m
• Compliances - IEC 62040-1; IEC 62040-2 C2; IEC 62040-3; IEC 62040-4; IEC 61643-11
• Conformity - CE / RCM

Dimensions W x H x D / Weight

• UPS Dimensions (mm) - 335x86x170
• UPS Weight (kg) - 4.3

*Backup times are approximate and may vary with equipment, configuration, battery age, temperature, etc.

Highlights

Complete protection for:

• Computers, peripherals and multimedia
• TV, video and Hi-Fi equipment: Home cinema, NAS, digital decoders, etc⋯
• Internet gateways
• Gaming console
• Broadband modems (Internet and TV) & IP telephony
• Household goods, etc⋯

Warranty Period

Warranty period: 24 months
Warranty terms: Return to base
